Features

• PCIe 2.0 Gen 1 compliant

• x1 Link, dual simplex, 2.5 Gbps in each direction

• Data read/write 32-bit operation

• Global interrupt status register for both UARTs

• 16 multi-purpose inputs/outputs (MPIOs)

• Two independent UART channels controlled with

• Support Bits per second Data transfer rates from 300 baud to 921600baud

• 16550 compatible register Set

• 256-byte TX and RX FIFOs

• MCU enable controls RS485 bidirectional data

Signal

• RS232:  DCD,RXD,TXD,DTR,GND,DSR,RTS,CTS,RI

• RS422:  TX - ,TX+, RX +,RX - GND

• RS485:  Data-, Data +

• Data bits：4,5,6,7,8

• Stop bits：1,1.5,2

• Parity bit：Odd, even, mark, space, None

• Flow control： None，Xon / Xoff, Hardware

• Operating Temperature：-40°C to +85°C

• Storage Temperature:-65°C to +150°C

System Requirements

• Windows® Server 2003, 2008, 2012,2016,2019

• Windows® XP, Vista, 7, 8,8.1,10

• Linux 2.6.27, 2.6.31, 2.6.32, 3.x.x and newer

• One PCI slot

Package Contents

• 1 × PCI TO RS232 Controll Card

• 1 × User Manual

• 2 × Low Profile
